Euro 6 Dongfeng Underlift Recovery Truck 12 Tonne Recovery Truck

6 TONS EURO 6 DONGFENG 12 TONS UNDERLIFT RECOVERY TRUCK LIFT AND BOOM TOW TRUCK WRECKER

Product Description

The light duty medium duty integrated series have different capacities from 3 tons to 10 tons.

The 6 ton Integrated wrecker body with a 13,500 lb. rated winch and underlift. A modern, modular steel body that is maximized for available storage and deck space. Optional aluminum body available.

The truck brand options also available with ISUZU, Dongfeng, HOWO, JAC, FOTON, JMC, FAW, SHACMAN, IVECO, etc.

With Euro 2, Euro 3, Euro 5, Euro 6 emission.

With RHD, LHD.

With 4x2, 4x4, 6x4, 6x6, 8x4, 8x8.

Other special requirements you want.

Main Features

1. 6 Tons / 13,500 lbs. Planetary Winch, 1 Pcs

2. 6 Tons / 13,500 lbs. Underlift Capacity, Tow Rate At Least 12 Tons / 26,600 lbs.

3. Optional Remote Control

4. Sides Tool Boxes

Truck Specs

6 Tons Integrated Wrecker Truck
Overview
Name	6 Tons Integrated Wrecker Truck
Dimension (LxWxH)	6450x2300x2400(mm)
Total Mass	9100Kg
Rated Payload	4000Kg
Kerb Weight	5900Kg
Passenger	3
The Parameters of Chassis
Manufacture/Model	Dongfeng
Driving Type	4*2 left hand drive
Wheel Base	3800 mm
Gearbox	Six speed forward and one reverse, manual
Tyre	7.50R16
The Number of Tyre	6+1(spare tyre)
Leaf Spring Number	8/10+7
AC, Power Window, Central Locking, etc.	Included
The Parameters of Engine
Manufacturer/Model	Yunnei/YCY24140-60
Rated Power	140hp
Fuel Type	Diesel oil
Displacement/Capacity	2360ml
Emission Standard	Euro 6
Cylinder	In-line/4/turbo/intercooling/+EGR+DOC+DPF+SCR+ASC
Max. torque	400N.m
Velocity	2950rpm

Body Specs

6 Tons Wrecker Body
S.N.	Item	Unit	Quantity	Remarks
1	Boom	Stage	2
2	Wheel Lift	Stage	2
3	Boom Extension Cylinder	pcs	1
4	Boom Lift Cylinder	pcs	2
5	Wheel Lift Extension Cylinder	pcs	1
6	Wheel Lift Tilt Cylinder	pcs	1
7	Multi Way Valve	pcs	1
8	Balance Valve	pcs	1	For boom lift
9	Pump	pcs	1
10	Winch	pcs	1	6 tons
11	Hose	set	1
12	Remote Control	set	1	Optional, extra USD500
13	Manual Control	side	2
14	Toolbox	side	2
15	Trolleys	pcs	2	Large trolley is optional, aluminum trolley is extra USD1000, steel trolley is extra USD800
16	Wheel Grids	pcs	2	Auto loader is optional, extra USD500
17	L Arms	pcs	2
18	Forks	pcs	2
19	Forks Holder	pcs	2
20	Binding Strips	pcs	4
21	Lights	set	1
