25 Tons Fifth Wheel Wrecker Attachment DTU Towing Unit Customization

Ask Lasest Price
Price :	$35000/units
Brand Name :	iTruck
Supply Ability :	5 unit/month
Delivery Time :	65 days

Add to Cart

Product Details
Company Profile

25 Tons Fifth Wheel Wrecker Attachment DTU Towing Unit Customization

Product Description

The DTU (Detachable Towing Unit) series has different capacities from 10 tons to 30 tons.

The 25 tons unit comes standard with 2 pcs of 22,000 lb planetary winch, 150’ of 7’’ wire rope and front legs that allow the unit to be easily removed in a matter of minutes so your truck can be multi-functional for both towing and pulling trailers. The DTU is designed to secure to your truck using a front lock-down bracket and your Fifth Wheel Plate. The power for the unit is provided by an hydraulic pump system, with quick connect couplers, which is installed on your truck. The DTU also comes with standard joystick remote control, it supports stable and safe operation.

Main Features

1. 20 Tons / 44100 lbs. Planetary Winch, 10 Tons, 2 Pcs

2. 25 Tons / 55100 lbs. Underlift Capacity, Tow Rate At Least 50 Tons / 110200 lbs.

3. Joystick Remote Control

4. Stainless Steel Tool Boxes

5. Low Profile Crossbar, min 12cm / 5.12 inch

Specs

25 Tons DTU
No.	Item	Content	Details	Unit
1	Name	25 Tons DTU
2	Winches	2×10 Tons Main Winches
3	Underlift	Underlift	G70 material, 3 stage
4	Boom	Boom	G70 material, 2 stage, hexagon
5	Stand	Front Manual Stand
6	Toolbox	Stainless Steel
7	Hook-Ups	Air and Electrical Hook-Ups	12V or 24V
8	Control	Remote Wireless Control	Joystick type, chest mount, English Indication
		Hand Manual Control	On Lift and Right Side, English Indication
9	Hydraulic Parts	Hydraulic Pump
		Hydraulic Hose
		Hydraulic Connector
		Valves
		Cylinders
10	Attachments	5 Sets of Forks	4 sets for axle, 1 set for suspension
		U shape tyres holder	1 set
		Safety Chains	2 pcs
11	Painting and Indication	Electrophoresis Painting	Boom, underlift and side boxes EP Painting
		Surface Painting	Epoxy Resin
		Indication	English Indication and Marks as per Miller
		Packaging	Boxes and underlift protected for the painting
Specifications
1	Underlift	Retracted Lifting Capacity	25000	kg
		Retracted Length	2100	mm
		Extended Lifting Capacity	6500	kg
		Extended Length	3200	mm
		Undelift Tilt	-10	°
		Towing Capacity	50	ton
2	Boom	Retracted Lifting Capacity (45°)	20	ton
		Extended Lifting Capacity (45°)	11.5	ton
3	Main Winches	Quantity	2	pcs
		Pulling Power	10	ton
		Type	Planetary
		Steel Wire Length	45	m
		Steel Wire Diameter	18	mm
